Solar water hater support frame production line-Tube holder
Application
Tank holder cover, cross pipe welding.
Also used for raw material coil welding connect, easy feed new coil to forming machines.
Description
Adopt the pulse welding controller, prevent welding discoloration, double conversion. Used copper braided conductive, high temperature resistant chromium zirconium copper electrode head, stable welding, sensitive point welding. Stamped on the lever to give pressure
Parameter data | |
Maximum welding plate thickness | 1.2mm+1.2mm Galvanized steel |
Main transformer Rated capacity | 50KVA |
Voltage | 380v 50HZ |
The secondary maximum short-circuit current | 20KA |
Duty cycle | 20% |
Labor | 1 people |
8 hours Max. Efficiency | 50PCS tube holder per set |
Weight | 150kg |
Floor space (L*W*H) mm | 800*500*1500 |
